Understanding the Risks and Challenges of Unreinforced Masonry Construction

Updated: Aug 7, 2023


unreinforced masonry brick wall

Unreinforced masonry (URM) refers to a construction technique that utilizes load-bearing walls made of brick, stone, or concrete blocks without any reinforcement, such as steel bars or mesh. While this construction method has been employed for centuries, it poses significant risks and challenges in terms of structural integrity and seismic performance. Let's dive into the characteristics, vulnerabilities, and historical context of URM, highlighting the importance of understanding its limitations in contemporary construction practices.

  1. What is Unreinforced Masonry? Unreinforced masonry involves the use of masonry units, including bricks, stones, or concrete blocks, to construct load-bearing walls without any additional reinforcement elements. It was widely popularized during the 19th and early 20th centuries due to its affordability, accessibility, and relative ease of construction.

  2. Structural Vulnerabilities: Unreinforced masonry structures are vulnerable to various structural issues, especially during seismic events. Some key vulnerabilities include: a) Low tensile strength: Masonry materials possess excellent compressive strength but lack adequate tensile strength, making them prone to cracking and failure under lateral loads. b) Brittle behavior: Unlike reinforced concrete, which exhibits ductile behavior, URM structures tend to fail abruptly without significant warning or deformation, leading to catastrophic collapses. c) Unbalanced loading: Due to the absence of reinforcement, URM walls may experience uneven loading, resulting in localized stress concentrations and potential collapse.

  3. Seismic Performance: Unreinforced masonry structures have historically performed poorly during earthquakes. Factors influencing their seismic vulnerability include: a) Poor lateral resistance: URM walls have limited capacity to resist horizontal forces, such as those generated during seismic shaking, leading to partial or total collapse. b) Vulnerability to out-of-plane failure: When subjected to lateral loads, URM walls can fail by overturning or by the outward movement of individual masonry units, jeopardizing the stability of the entire structure. c) Potential for progressive collapse: The failure of a single URM wall segment can trigger a chain reaction, causing adjacent walls to collapse, resulting in the progressive collapse of the entire structure.

  4. Historical Context: Many older cities around the world still contain significant numbers of URM buildings. Understanding the historical context helps shed light on the prevalence and challenges associated with these structures. Examples include: a) The 1906 San Francisco earthquake: The devastating earthquake highlighted the vulnerability of URM buildings, leading to the implementation of seismic building codes and retrofitting requirements. b) European historical heritage: Numerous historic cities in Europe feature URM structures, necessitating careful preservation and retrofitting efforts to enhance their resilience to seismic activity.

  5. Mitigation Strategies: To address the risks posed by URM structures, several mitigation strategies are employed: a) Seismic retrofitting: Techniques like adding steel bracing, shear walls, or fiber-reinforced polymers can enhance the lateral resistance of URM buildings, reducing the risk of collapse during earthquakes. b) Building codes and regulations: Implementation and enforcement of stringent building codes ensure that new construction projects adhere to seismic design requirements, discouraging the use of URM in seismically active regions. c) Public awareness and education: Promoting awareness among building owners, architects, engineers, and the general public about the risks associated with URM construction can facilitate informed decision-making regarding maintenance, retrofitting, or replacement of these structures.

Unreinforced masonry construction, while historically significant, presents numerous challenges in terms of structural integrity and seismic performance. The vulnerabilities of URM buildings emphasize the need for proactive measures such as seismic retrofitting, improved building codes, and public awareness to ensure the safety and resilience of our built environment. By understanding the risks associated with URM, we can work towards preserving historic structures and constructing safer buildings that can withstand the forces of nature.


Curious whether your commercial property might be at risk due to unreinforced masonry? Reach out to the experienced team here at Seattle Seismic for a free assessment and consultation. Book an appointment today.
